Hikvision DS-2DF8A442IXS-AF/SP(T5)

Kamera

Image Sensor1/1.8" progressive scan CMOS Min. IlluminationColor: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @ (F1.2，AGC ON), 0 Lux with IR Shutter Speed1/1 s to 1/30,000 s Slow ShutterYes Day & NightIR cut filter Zoom42x optical, 16x digital Max. Resolution2560 × 1440

Lens

FocusAuto, semi-auto, manual, rapid focus Focal Length6.0 mm to 252 mm Zoom SpeedApprox. 4.5 s

FOV

Horizontal field of view: 56.6° to 1.7° (wide-tele),Vertical field of view: 33.7° to 0.9° (wide-tele),Diagonal field of view: 63.4° to 1.9° (wide-tele)ApertureMax. F1.2

Illuminator

Supplement Light TypeIR Supplement Light Range500 m Smart Supplement LightYes

PTZ

Movement Range (Pan)360° Movement Range (Tilt)-20° to 90° (auto flip) Pan SpeedPan speed: configurable from 0.1° to 210°/s; preset speed: 280°/s Tilt SpeedTilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s Proportional PanYes Presets300 Patrol Scan8 patrols, up to 32 presets for each patrol Pattern Scan4 pattern scans, record time over 10 minutes for each scan Power-Off MemoryYes Park ActionPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan 3D PositioningYes PTZ Status DisplayYes Preset FreezingYes Scheduled TaskPreset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

Video

Main Stream

50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264/MJPEG Video Bit Rate32 Kbps to 16384 Kbps H.264 TypeBaseline Profile/Main Profile/High Profile H.265 TypeMain Profile Scalable Video Coding (SVC)H.264 and H.265 encoding Region Of Interest (ROI)8 fixed regions for each stream

Audio

Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)

Network

Network StorageNAS (NFS, SMB/ CIFS), ANR ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour APIISUP, ISAPI, Hikvision SDK, Open Network Video Interface (Profile S, Profile G, Profile T) Simultaneous Live ViewUp to 20 channels User/HostUp to 32 users. 3 levels: Administrator, Operator and User

SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)

ClientHikCentral, iVMS-4200, Hik-Connect

Web BrowserIE11, Chrome 57.0+, Firefox 52.0+, Safari 11+


Image SettingsSaturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser

Day/Night SwitchDay, night, auto, scheduled-switch

Image EnhancementBLC, HLC, 3D DNR

Wide Dynamic Range (WDR)140 dB WDR

DefogOptical defog

Image StabilizationYes. Built-in gyroscope to improve EIS performance.

Regional ExposureYes

Regional FocusYes

Privacy MaskUp to 24 masks, polygon region, mosaic mask, mask color configurable

SNR≥ 52 dB

Supplement Detection

Satellite PositioningYes

CompassYes

Interface

Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port

Fiber OpticalFC interface, built-in fiber module (100 M, TX1310/RX1550nm wavelength, single module fiber, up to 20 km transmission distance)

On-Board StorageBuilt-in memory card slot, support MicroSD/MicroSDHC/MicroSDXC, up to 256 GB

Alarm7 inputs, 2 outputs

Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω

Video Output1.0V[p-p]/75Ω, PAL, NTSC, BNC connector

RS-485HIKVISION, Pelco-P, Pelco-D, self-adaptive

Event

LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,and PTZ actions (such as preset, patrol scan, pattern scan)

Basic EventMotion detection, video tampering alarm, alarm input and output, exception

Smart EventLine crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, vandal-proof alarm, audio exception detection

Smart TrackingManual tracking, auto-tracking

Deep Learning Function

Face CaptureSupport detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face

Face ComparisonYes

Perimeter Protection

Line crossing, intrusion, region entrance, region exiting

Support alarm triggering by specified target types (human and vehicle)

Road Traffic And Vehicle Detection

Road TrafficSupport vehicle detection (license plate number,vehicle model, and vehicle color recognition)

General

General FunctionMirror, password protection, watermark, IP address filter

Power24 VAC (Max. 60 W, including max. 18 W for IR and max. 6 W for heater)

Operating ConditionTemperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%

Dimension⌀ 267 mm × 405 mm (⌀ 10.51" × 15.94")

WeightApprox. 8.5 kg (18.74 lb.)

Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Approval

EMC

FCC SDoC (47 CFR Part 15, Subpart B);

CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);

RCM (AS/NZS CISPR 32: 2015);

IC VoC (ICES-003: Issue 6, 2019);

KC (KN 32: 2015, KN 35: 2015)

Safety

UL (UL 62368-1)

CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);

CE-LVD (EN 62368-1:2014+A11:2017),

BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);

LOA (SANS IEC60950-1)

Environment

CE-RoHS (2011/65/EU); WEEE (2012/19/EU);

Reach (Regulation (EC) No 1907/2006)

ProtectionIP67 Standard, Lightning Protection, Surge Protection and Voltage Transient Protection, ±6kV Line to Gnd, ±3kV Line to Line, IEC61000-4-5, IK10
